Name of Colormeter for Petroleum Products / OME 2000
This is a color measuring instrument for petroleum products used to measure liquid colors of petroleum oil and greases. It has the equivalent function as that of a colormeter, and its measurements are made according to such industrial standards as JIS, ASTM and ISO. So, highly reliable and accurate color evaluation of your oil samples will be made possible. Measurements by this model are traceable to the standard color liquids specified by the relating industrial standards, the data of which have been saved into a memory of this instrument as such standard color data. Inconvenient calibration using a standard color plate is not needed accordingly, and everyone can use this model so easily. Photo of Colormeter for Petroleum Products / OME 2000
Features of Colormeter for Petroleum Products / OME 2000
01
Colors of petroleum oilsa and greases are explicitly displayed with the values corresponding to the JIS (or ASTM, etc.).
02
Thanks to its compact all-in-one type design with user-friendly operation, you will be able to install it anywhere.
03
By adoption of unique compensation circuit, stable data of measurements can be obtained even for long hours of use.
04
It is possible to measure Saybolt color, ASTM color, Harzen color number (APHA) and Gardner color.
05
Measurement using a test tube is also possible in option.
Specifications of Colormeter for Petroleum Products / OME 2000
Dimensions
W 400mm x D 400mm x H 210mm
Weight
Approx. 12kg
Power supply
100V to 240V AC, 50 / 60Hz
Power consumption
120VA
Light source
Halogen lamp, 12V 2A
Measuring items
ASTM color, Saybolt color,
Harzen color number (APHA), Gardner color, XYZ,
L*a*b*
Measuring range
ASTM : 0 to 8.0, Saybolt : 30 to -16,
APHA (Pt-Co) : 0~500, Gardner : No.1 to No.18
Measuring area
16mmΦ (luminous flux aperture of transmittance)
Related standards
ASTM, Saybolt, APHA (Pt-Co), Gardner : JIS K 0071
ASTM, Saybolt : JIS K 2580
APHA (Pt-Co) : ISO 2211, ISO 6271
Gardner : ISO 4630, ASTM D 6045-95,
ASTM D 1209-84, ASTM D 156-94,
ASTM D 1500-91, ASTM D 1544-80
Measurement accuracy
ASTM 1.0 : CV value within 3%
Saybolt 30 : CV value within 2%
*This instrument is traceable to the standard of Japan Color Research Institute (JCRI).
